Reliable, efficient,
and modular

• Battery can be mounted in three different orientations, enhancing its adaptability
• Integrated charger controls
• UN38.3 certified: approved for global shipping
• Rated capacity of 4.5 kWh/100 Ah
• Scalable: increase capacity without additional controllers
• High voltage: connect modular packs in series for systems up to 500V
• Environmental protection enclosure: fully plastic case (IP66)

Turntide’s new lithium-ion modular battery solutions combine high-performance battery packs with system controllers for temperature and voltage measurement and internal cell balancing. The battery pack is ideal for many off-highway applications from construction and agriculture to marine and material handling.

• Battery can be mounted in three different orientations, enhancing its adaptability
• Integrated charger controls
• UN38.3 certified: approved for global shipping
• Rated capacity of 6.7 kWh/150 Ah
• Scalable: increase capacity without additional controllers
• High voltage: connect modular packs in series for systems up to 500V
• Environmental protection enclosure: fully plastic case (IP66)

Turntide’s new lithium-ion modular battery solutions combine high-performance battery packs with system controllers for temperature and voltage measurement and internal cell balancing. The battery pack is ideal for many off-highway applications from construction and agriculture to marine and material handling.

• SIL2 (equivalent to ASIL-C) approved Battery Management System.
• Contactor control with anti-valent feedback.
• Proprietary CAN communications.
• Series and Parallel configurations to meet power and voltage requirements.
• Patented active cooling solution.
• Data collection for maintenance management.

High Performance Lithium-ion NMC Battery Pack with built-in intelligent Battery management.

Designed to support the ambitious decarbonization goals to bring all greenhouse gas emissions to net zero. With High energy and high-power capabilities replacing diesel power generation in multiple applications. Fully type-approved for use on rail and non-rail applications.

• 500k baud CAN communication for system data and battery controls (compliant with J1939)
• Management of battery voltage, temperature, cell balancing and load current limits
• State of Charge (SoC) and State of Health (SoH) battery tracking and reporting
• DC Bus and Pre-charge Contactor management
• HVIL management
• Battery Charger management

The Turntide BCU (Battery Control Unit) is cell agnostic and flexible over multiple system voltages and parallel/serial battery pack arrangements.

The BCU works with IsoSPI networked battery-based CMUs (Cell Monitoring Unit) which connect to, control and monitor the voltage and temperature of a set of battery cells. The BCU provides the management for the CMU connected battery cells, the battery system & wider system integration.
