power electronics

Proven Solutions

Experience Turntide’s power electronics: reliable high-voltage inverters, low-voltage motor controllers, and DC/DC converters, designed for traction, generation, and auxiliary functions like pumps and fans. Explore our datasheets for more details.


Tech Tour

Gen 6 Inverter

NEW!
3d icon
Inverter--Whitehaven-Size-6

Gen 6 - S Series

Working Voltage Range (V)
20 - 63
Min battery voltage (V)
20
Boost current 10 sec (Arms)
600 - 800
Peak current (2 min) (Arms)
450 - 650
Continuous (60 min) (Arms)
190 - 250
Coolant
Air
Controller functionality
Yes
NEW!
3d icon
Inverter--Whitehaven-Size-6

Gen 6 - X Series

Working Voltage Range (V)
20 - 135
Min battery voltage (V)
20
Boost current 10 sec (Arms)
480 - 800
Peak current (2 min) (Arms)
360 - 650
Continuous (60 min) (Arms)
150 - 250
Coolant
Air
Controller functionality
Yes
DC Logic Supply (V)
6 - 16
HVLP10 inverter

Turntide Gen 4 HVLP10

Nominal (VDC)
700
100% derating (VDC)
800
Min battery voltage (V)
128
Peak current (1 min) (Arms)
24*
Continuous (60 min) (Arms)
19*
Coolant
Air
Controller functionality
No
Turntide HVLP20 inverter

Turntide Gen 4 HVLP20

Nominal (VDC)
700
100% derating (VDC)
800
Min battery voltage (V)
128
Peak current (1 min) (Arms)
53
Continuous (60 min) (Arms)
33
Coolant
Liquid
Controller functionality
No
Turntide gen 4 size 6 inverter

Turntide Gen 4, Size 6 (48V, 650A)

Nominal (VDC)
48
100% derating (VDC)
69.6
Min battery voltage (V)
19.3
Boost current 10 sec (Arms)
780
Peak current (2 min) (Arms)
650
Continuous (60 min) (Arms)
260
Coolant
Air
Controller functionality
Yes
Turntide gen 4 size 4 inverter

Turntide Gen 4, Size 4 (80V, 350A)

Nominal (VDC)
80
100% derating (VDC)
116
Min battery voltage (V)
39.1
Boost current 10 sec (Arms)
420
Peak current (2 min) (Arms)
350
Continuous (60 min) (Arms)
140
Coolant
Air
Controller functionality
Yes
Turntide gen 4 size 4 inverter

Turntide Gen 4, Size 4 (48V, 450A)

Nominal (VDC)
48
100% derating (VDC)
69.6
Min battery voltage (V)
19.3
Boost current 10 sec (Arms)
540
Peak current (2 min) (Arms)
450
Continuous (60 min) (Arms)
180
Coolant
Air
Controller functionality
Yes
Turntide gen 4 size 2 inverter

Turntide Gen 4, Size 2 (48V, 275A)

Nominal (VDC)
48
100% derating (VDC)
69.6
Min battery voltage (V)
19.3
Boost current 10 sec (Arms)
330
Peak current (2 min) (Arms)
275
Continuous (60 min) (Arms)
110
Coolant
Air
Controller functionality
Yes

Turntide Gen 5, Size 9

Nominal (VDC)
350
100% derating (VDC)
450
Min battery voltage (V)
128
Boost current 10 sec (Arms)
450
Peak current (2 min) (Arms)
400
Continuous (60 min) (Arms)
200
Coolant
Liquid
Controller functionality
Yes
Turntide Gen 5 size 9 inverter

Turntide Gen 6, Size 9

Nominal (VDC)
350
Maximum Voltage (without derating)
450
Min battery voltage (V)
128
Boost current 10 sec (Arms)
450
Peak current (1 min) (Arms)
400
Continuous (60 min) (Arms)
200
Coolant
Liquid
Controller functionality
No
48V-DCDC-14V-500W DCDC Converter

Turntide DC/DC Converter (500W)

Output power
500W
Output voltage options
12–14V
Temperature range
-40ËšC to +85ËšC

* Subject to confirmation of validation testing
